High Power Waveguide Differential Phase Shift Circulator
High Power Waveguide Differential Phase Shift Circulator Introduction
The High Power Waveguide Differential Phase Shift Circulator is an advanced microwave component engineered to handle high-power signals with exceptional efficiency and reliability. Designed for applications in satellite communications, aerospace, defense, and radar systems, this circulator provides stable signal routing and reduced transmission losses. With over 30 years of expertise, Advcanced Microwave Technologies Co., Ltd delivers cutting-edge solutions tailored to meet diverse operational demands.
Product Specifications
Model No* | Freq Range(GHz) | Working Bandwidth | VSWR | IL (dB) | Isolation (dB) | Avg Power (W) | Flange | Material | Finish |
ADM-14WHPDPSI40KW | 1.13-1.73 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 40k | FDP | Al | Chromate conversion |
ADM-18WHPDPSI30KW | 1.45-2.20 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 30k | FDP | Al | Chromate conversion |
ADM-22WHPDPSI20KW | 1.72-2.61 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 20k | FDP | Al | Chromate conversion |
ADM-26WHPDPSI20KW | 2.17-3.30 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 20k | FDP | Al | Chromate conversion |
ADM-32WHPDPSI10KW | 2.60-3.95 | ≤5% | ≤1.2 | ≤0.4 | ≥20 | 10K | FDP | Al | Chromate conversion |
ADM-40WHPDPSI5KW | 3.22-4.90 | ≤5% | ≤1.2 | ≤0.4 | ≥20 | 5K | FDP | Al | Chromate conversion |
ADM-48WHPDPSI8KW | 3.94-5.99 | ≤5% | ≤1.2 | ≤0.4 | ≥20 | 8K | FDP | Al | Chromate conversion |
ADM-84WHPDPSI1200W | 6.57-9.99 | ≤7% | ≤1.25 | ≤0.4 | ≥20 | 1.2K | FBP | Cu | Silver Plating |
ADM-100WHPDPSI1000W | 8.2-12.5 | ≤7% | ≤1.25 | ≤0.5 | ≥20 | 1K | FBP | Cu | Silver Plating |
ADM-120WHPDPIC1000W | 9.84-15.0 | ≤7% | ≤1.25 | ≤0.5 | ≥20 | 1K | FBP | Cu | Silver Plating |
ADM-140WHPDPSI800W | 11.9-18.0 | ≤7% | ≤1.25 | ≤0.5 | ≥20 | 800 | FBP | Cu | Silver Plating |
ADM-180WHPDPSI800W | 14.5-22.0 | ≤7% | ≤1.25 | ≤0.5 | ≥20 | 800 | FBP | Cu | Silver Plating |
High Power Waveguide Differential Phase Shift Circulator Benefits
- Superior Signal Stability: Ensures uninterrupted communication with minimal distortion.
- High Efficiency: Optimized for high power transmission while maintaining low insertion loss.
- Durable Design: Built for reliability in extreme environmental conditions.
- Compliance-Ready: Fully RoHS-compliant and ISO-certified, ensuring international quality and sustainability standards.
Technical Features
- Differential Phase Shift: Advanced design for precise signal phase control, crucial for radar and navigation systems.
- Customizable Waveguide Interfaces: Adaptable to specific frequency ranges and dimensions.
- Enhanced Power Handling: Designed for high-power applications, suitable for both commercial and defense sectors.
- Low Transmission Loss: Minimizes energy loss, improving overall system performance.
Product Applications
The High Power Waveguide Differential Phase Shift Circulator is indispensable in the following domains:
- Satellite Communications: Ensures clear and stable transmission across vast distances.
- Radar Systems: Provides reliable signal phase control for accurate target detection.
- Aerospace: Supports high-frequency communication and navigation in aircraft and spacecraft.
- Defense Applications: Integral in advanced weaponry systems requiring stable and precise signal routing.
OEM Services
At Advcanced Microwave Technologies Co., Ltd, we understand the importance of flexibility. Our OEM services include:
- Customization Options: Tailor the waveguide size, material, and frequency range to meet specific requirements.
- Technical Support: Installation guidance, product matching, and fault diagnostics to ensure optimal performance.
- Fast Turnaround: Quick response to orders and reliable global delivery.
FAQ
Q1: What makes this circulator suitable for high-power applications?
A1: The circulator is engineered with high-power capacity and low insertion loss, making it ideal for demanding systems like radar and satellite communication.
Q2: Can the circulator be customized for unique frequency ranges?
A2: Yes, we offer comprehensive customization services to adapt the circulator to your specific frequency and operational needs.
Q3: What certifications does this product hold?
A3: The circulator meets ISO 9001:2008 standards and is RoHS-compliant, ensuring quality and environmental sustainability.
