High Power Waveguide Circulator
High Power Waveguide Circulator Introduction
Presenting the High Power Waveguide Circulator, a state-of-the-art part intended to maximize signal transmission in sophisticated radar and communication systems. Advcanced Microwave Technologies Co., Ltd. has been producing microwave components for more than 30 years. They offer industry-leading circulators that provide exceptional performance and dependability for demanding applications. In high-frequency systems, these devices are essential for guaranteeing stable signal directionality and low transmission loss.
Product Specifications
Model No* | Freq Range(GHz) | Working Bandwidth | VSWR | IL (dB) | Isolation (dB) | Avg Power (W) | Flange Type | Material | Finish |
ADM-14WHPCIC20K | 1.13-1.73 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 20K | FDP | Al | Chromate conversion |
ADM-18WHPCIC1000 | 1.45-2.20 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 1000 | FDP | Al | Chromate conversion |
ADM-22WHPCIC1000 | 2.2-2.55 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 1000 | FDP | Al | Chromate conversion |
ADM-26WHPCIC1000 | 2.17-3.3 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 1000 | FDP | Al | Chromate conversion |
ADM-32WHPCIC1000 | 2.60-3.95 | ≤5% | ≤1.2 | ≤0.3 | ≥20 | 1000 | FDP | Al | Chromate conversion |
ADM-48WHPCIC1000 | 3.94-5.99 | ≤10% | ≤1.2 | ≤0.3 | ≥20 | 1000 | FDP | Al | Chromate conversion |
ADM-58WHPCIC1000 | 4.64-7.05 | ≤10% | ≤1.2 | ≤0.3 | ≥20 | 1000 | FDP | Al | Chromate conversion |
ADM-70WHPCIC400 | 5.38-8.17 | ≤10% | ≤1.2 | ≤0.3 | ≥20 | 400 | FDP | Al | Chromate conversion |
ADM-84WHPCIC400 | 6.57-9.99 | ≤10% | ≤1.2 | ≤0.3 | ≥20 | 400 | FBP | Al | Chromate conversion |
ADM-100WHPCIC300 | 8.2-12.4 | ≤15% | ≤1.2 | ≤0.3 | ≥20 | 300 | FBP | Al | Chromate conversion |
ADM-120WHPCIC100 | 9.84-15.0 | ≤15% | ≤1.2 | ≤0.3 | ≥20 | 100 | FBP | Al | Chromate conversion |
ADM-140WHPCIC150 | 11.9-18.0 | ≤15% | ≤1.2 | ≤0.3 | ≥20 | 150 | FBP | Al | Chromate conversion |
ADM-180WHPCIC100 | 14.5-22.0 | ≤15% | ≤1.25 | ≤0.3 | ≥20 | 100 | FBP | Al | Chromate conversion |
ADM-220WHPCIC80 | 17.6-26.7 | ≤15% | ≤1.25 | ≤0.3 | ≥20 | 80 | FBP | Cu | Silver Plating |
ADM-260WHPCIC40 | 21.7-33.0 | ≤15% | ≤1.25 | ≤0.3 | ≥20 | 80 | FBP | Cu | Silver Plating |
ADM-320WHPCIC40 | 26.5-40 | ≤15% | ≤1.25 | ≤0.3 | ≥20 | 50 | FBP | Cu | Silver Plating |
ADM-400WHPCIC3 | 32.9-50.1 | ≤5% | ≤1.25 | ≤0.5 | ≥20 | 3 | FUGP | Cu | Gold Plating |
High Power Waveguide Circulator Benefits
- Improved Signal Performance: High Power Waveguide Circulator provides low transmission loss support for high-frequency bands.
- High Durability: Long-term performance is ensured by design for harsh environmental conditions.
- Customizable Options: Made to fit your unique technical specifications.
- Eco-Friendly Compliance: Sustainable and eco-friendly materials are guaranteed by RoHS certification.
Technical Features
- Advanced Design: Optimal isolation and minimal insertion loss are guaranteed by precise engineering.
- High Power Handling: Able to control power levels for demanding applications up to 500 watts.
- Versatility in Frequency: Effectively functions at a variety of frequencies (up to 110 GHz).
- Robust and Compact: Durability is maintained without sacrificing ease of integration due to the lightweight design.
Applications
- Satellite communications: Provides stable signals and dependable data transfer in satellite systems.
- Radar systems: By guaranteeing effective signal circulation, they improve detection accuracy.
- Telecommunication Base Stations: Enhance network efficiency by optimizing signal directionality.
- Aerospace and Defense: Essential to sophisticated electronic warfare, surveillance, and navigation systems.
OEM Services
To satisfy a range of industry demands of High Power Waveguide Circulator, Advanced Microwave Technologies Co., Ltd. provides extensive OEM services:
- Custom Design: Modify the frequency range, material, and waveguide size.
- Technical advice: This covers product matching and installation assistance.
- Quick turnaround times for personalized solutions are a benefit of rapid prototyping.
- Worldwide Delivery: Guarantees a steady and effective supply chain.
Frequently Asked Questions
1. What is a Circulator used for?
It ensures stable signal circulation and minimal loss in high-power communication and radar systems.
2. Can you customize the circulator to specific requirements?
Yes, we offer customization services for size, frequency range, material, and other parameters.
3. Are your products certified?
All our products are ISO 9001:2008 certified and RoHS compliant.
4. What industries benefit most from your circulators?
Industries like satellite communications, aerospace, defense, and telecommunications widely use our circulators.
